Friday 1 April 2022

Mini PET 40/80 Advanced Level Kit

We have had a lot of feedback on the Mini PET 40/80 kits, everyone seems to like them, which is great. However, one issue keeps coming up, apparently the kits I make are too easy to assemble.

Introducing the Advanced Level kits.

With these, I have tried to make things a bit more difficult, and have removed some of the helpful hints you used to get, like silkscreen component values.

Component placement is now more of a challenge, take all the parts provided, and attempt to arrange them into a working machine.

The boards aren't entirely blank of course, there is a model and version number on the back for reference.

Further hints will eventually be provided if no one manages to find the solution.

Also, we found that some people didn't like having to cut up the paper labels for the keyboard keys, so they have now been colour coded instead of using the labels.

Obviously, with a kit like this, detailed instructions would normally be required. The foremost technical authors of the land have provided such a manual.

They would be grateful if you could fill it in as you go.

So there you have it, the advanced difficultly level Mini PET 40/80 kit.

Available now from


The actual Mini PET 40/80 kits are all sold out, but there are some Mini PET 40/80D boards still available from TFW8b (whilst stocks last)

Minstrel 4D

If you fancy a kit with full instructions, the Minstrel 4D kits are shipping now, you can order one from The Future Was 8 bit - SPECIAL OFFER - £15 off the Minstrel 4D and free shipping to the USA.

Now also includes an option to have you kit built and tested if you don't fancy doing any soldering.

More info in a previous post:


You can support me via Patreon, and get access to advance previews of posts like this and behind the scenes updates. These are often in more detail than I can fit in here, this post contains bits from several Patreon posts. This also includes access to my Patreon only Discord server for even more regular updates.

Oh, and if anyone wants to buy the built "Mini PET Stealth", let me know.
